不同的用途与详细介绍/Brief introduction:

机器是在扶植和吸纳美国先进集体方法的核心上，我单位独立自主研发部的有款专科应对内服液和糖浆的灌装设备、上塞、旋（轧）盖机。机器适用日式全原产高精密度较半密闭式凸轮轴度数卡位器，精密度较高，进行信得过，采用期限长。该度数器结构类型很简单，持续采用就不需要维修培训。该机通常选用做多种口服方式液及糖吸收塔体的罐装、压塞及旋（轧）盖，宽泛用做调味品、药业有限公司、有机化工该行业及科学教育领域。完完全全非常符合国GMP想要。NFGX-30/100 Automatic Oral&sSyrup Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.This machine is suitable for oral and syrup liquid filling&capping. Widely used in food, pharmaceutical, chemical industries and scientific research.Full compliance with the GMP requirements.

优缺点/Characteristic：

◆组队画质有效控制在、实操更直观便、PLC有效控制，装量*。Human-machine interface settings, an easy and intuitive, PLC control.◆调频把控、制造车速指定可以调节、自己运算。Frequency control, the production rate be adjusted automatically count. ◆自动的暂停服务效果，无瓶不分装。No bottle no filling. ◆高可靠性强，精密度凸轮机构量程计掌握，定位系统*。High-precision cam meter control, precise positioning◆主要采用SUS304及316L不锈钢圆管制做，截然按照GMP想要。SUS304 and 316L stainless steel, full compliance with GMP requirements.

技术应用参数表/ technical parameters：

装量比率Filling volume	30-150ML
装量数据误差loading error	≤ ±1%
旋（轧）盖通过率Rotation (rolling) Cover pass rate	≥99%
生產技能 Production capacity	30-60瓶/分 钟  中速 70-100瓶/分 钟&nbs🀅p;    高速的 30-60 bottles / min  70-100 bottles / min
电原Power	380V/50Hz
马力Power	2.0 kw
丝机净重量Net weight	600 kg
性能尺寸规格Dimension	2000*1000*1500mm
