功用与详细介绍/Brief Introduction：

全自動注塞泵式膏体酱罐装设备机就是你集团融入制造业市场标准开放的新设备。该机型利用SUS304铝合金注塞泵式量值溯源泵执行力罐装设备，且集自動上盖、自動旋盖、机电工程高压电器为一体化，经济增长方便使用，土地征用适用面积小，密切用途于药业、食品厂、除草剂、所有、美容品等制造业的固态木箱，按照GMP实验室管理标准规范要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优点/characteristic：

◆选用了柱塞泵式测量泵实行灌装设备，适合多种胶状度液态，要求高；泵的组成部分选用了快接式拆换系统，于清洁工作、空气消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式计量校准泵缸筒环所选材質通过制造行业及液體物质的不一样的利用硅产品，四氟丁二烯或其它的所选材質，层次性场景利用淘瓷所选材質。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC把控好体系，直流变频调速器，自己化数量高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装线，自主计数法效果。Lack of bottle filling, automatic counting function◆装量调节简单，可是一次调节全都量值溯源校准泵的充填量，也可共性不同量值溯源校准泵通过微幅调节；控制简单方便，调节高效。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装设备针头均有防滴漏问题传动装置，充填时前往瓶底包装设备，缓缓飙升，以避免小气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆一整台机器的可可用有差异 要求的空瓶，变动简单便捷，可在间歇间内达到。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆一整台机器的按GMP标准要求设定。The machine designed according to the requirements of GMP

技术应用主要参数/technic parameter：

用于可乐瓶样式Size of bottles	20-1000ml（表明追求生产厂家）20-1000 - ml (according to your need）
适合玻璃瓶长度Apply the bottle diameter	¢20-¢150mm
采用盖子品种Apply the lid specifications	¢20-¢70mm
生产制造力 production capacity	四头装罐：1000-2500瓶/h Four filling head: 1000-2500 bottles per hour 八头灌装生产线：2500-4000瓶/小时内 Eight head filling: 2500-4000 bottles per hour 12头包装：4000-6000瓶/时间 12 head filling: 4000-6000 bottles per hour
装量随机误差The load error	±1%
旋盖适合率Screw cover percent of pass	≥99%
电源线power supply	380V，50HZ
电功率power	3.0KW
汽源gas sources	0.4-0.75MPA
高速度设定speed control	调频调节variable speed
